The MPM6010 Buck LED Driver is a 36V/1.5A high efficiency synchronous LED driver with integrated inductor. These drivers provide a compact solution with built-in power MOSFETs and two capacitors, requiring only four external components. This allows 1.5A of continuous output current and excellent load and line regulation over a wide input supply range. Protection features include thermal shutdown (TSD), overcurrent protection (OCP) with valley current detection, and internal soft-start. The modules are available in a QFN-17 (3mm x 5mm x 1.6mm) space saving package. AEC-Q100 qualified drivers are available. The MPS MPM6010 buck LED driver is ideal for automotive LED lighting applications.

Specifications

Type Constant Current

Topology Buck

Number of outputs 1

Voltage - Input (min) 4V

Voltage - Input (Max) 36V

Voltage - Output -

Current - Output (Max) 1.5A

Dimming PWM

Features OCP, OTP, SCP, UVLO

Operating temperature -40°C ~ 125°C

efficiency -

Mounting Type Surface Mount, Wettable Flanks

Package/Enclosure 17-PowerLQFN Module

Size / Dimensions 0.12"L x 0.20"W x 0.06"H (3.0mm x 5.0mm x 1.7mm)

Certification Body -

Base Product Number MPM6010

Application

Automotive LED Lighting

reading light

dome light

puddle lights

map light

Daytime Running Lights (DRL)

spare light
