TLV320AIC33IZXH is a low power stereo audio codec with stereo headphone amplifier, as well as multiple inputs and outputs programmable in single-ended or fully differential configurations.

Features

Stereo Audio DAC

100-dBA Signal-to-Noise Ratio

16/20/24/32-Bit Data

Supports Rates From 8 kHz to 96 kHz

3D/Bass/Treble/EQ/De-emphasis Effects

Stereo Audio ADC

92-dBA Signal-to-Noise Ratio

Supports Rates From 8 kHz to 96 kHz

Ten Audio Input Pins

Programmable in Single-Ended or Fully Differential Configurations

3-State Capability for Floating Input Configurations

Seven Audio Output Drivers

Stereo 8-2, 500-mW/Channel Speaker Drive Capability

Stereo Fully Differential or Single-Ended Headphone Drivers

Fully Differential Stereo Line Outputs

Fully Differential Mono Output

Low Power: 14-mW Stereo 48-kHz Playback With 3.3-V Analog Supply

Programmable Input/Output Analog Gains

Automatic Gain Control (AGC) for Record

Programmable Microphone Bias Level

Programmable PLL for Flexible Clock Generation

Control Bus Selectable SPI or rc

Audio Serial Data Bus Supports 2s,LeftRight-Justified, DSP, and TDM Modes

Digital Microphone Input Support

Extensive Modular Power Control
