The ACS770KCB-150B-PFF-T current sensor IC provides an affordable and accurate solution for AC or DC influenza measurement. The device offers a wide current detection range of 150A and operates with a 5V supply voltage. Typical applications include motor applications, load detection and management, power and DC-DC converter control, converter control, and overcurrent protection.

Product specification

Used for measurement: AC/DC

Sensor type: Hall effect, open loop

Current - Detection: 150A

Number of channels: 1

Output: ratio, voltage

Sensitivity: 13.3mV/A

Frequency: DC ~ 120kHz

Linearity: ±1%

Accuracy: ±0.6%

Voltage - Power supply: 5V

Response time: 4.6µs

Current - Power supply (Max.) : 15mA

Operating temperature: -40°C ~ 125°C

Polarization: bidirectional

Installation type: Through hole

Package/Housing: 5-CB shaped lead, PFF

Supplier device package: 5-CB module
