The AVR16DD14T-I/SLwill be available in TQFP and VQFN package options running at up to 24 MHz and with 16 KB Flash, 2 KB SRAM, and 256B of EEPROM.

The AVR16DD14T-I/SL product supports four Multi-Voltage I/O channels capable of bi-directional communication with external devices running at a higher or lower voltage than the MCU itself. The MVIO system makes the AVR® DD a perfect device for board control, sensor applications, IoT end nodes, and other size constrained applications, and for sensor fusion in larger systems.

Product Features

Functional Safety

Appliances safety - IEC 60730 (Class B)

Industrial safety – IEC 61508 (SIL)

Automotive safety – ISO 26262 (ASIL)

High-Performance AVR RISC CPU with Hardware Multiplier

Running up to 24 MHz

External High-Frequency Oscillator

Single Cycle I/O Access

Two-level Interrupt Controller

Sleep Modes: Idle, Standby, Power-down

Multi-Voltage I/O (MVIO)

Event System (EVSYS)

Configurable Custom Logic (CCL)

Single pin programming and debugging interface (UPDI)

Analog Features

12-bit Differential Analog-to-Digital Converter (ADC)

10-bit Digital-to-Analog Converter (DAC) with Output Buffer

Zero-Cross Detector (ZCD)

Analog Comparator

Timer/Counters

Timer/Counter type A (TCA)

Timer/Counter type B (TCB)

Timer/Counter type D (TCD) for control applications

Communication

Serial communication interfaces: USART, SPI, I2C

Built-in Safety Functions:

Clock Failure Detection (CFD)

Power-On Reset (POR)

Brown-Out-Detection (BOD)

Voltage Level Monitor (VLM)

Cyclic Redundancy Check (CRC) Scan

Window Watchdog Timer with Window Mode (WWDT)
