KK28FN2M0CAU15 The Kinetis K28 USB Arm® Cortex®-M4 MCUs target applications requiring processing efficiency and extra-large embedded memory with 2 MB Flash and 1 MB SRAM.

Product Features

150 MHz (max) Cortex-M4 with DSP instructions and Single Precision Floating Point unit (FPU)

32-channel DMA with asynchronous support in Stop mode

Crossbar switch enables concurrent multi-leader bus accesses, increasing bus bandwidth

ctive run power core consumption @120Mhz: <258 µA/MH (TYP) (@25C) running from internal flash

Static power consumption down to <14µA with full 1MB SRAM retention and <6 µS wakeup

Lowest static mode down to 254 nA (VLLS0)

2 MB dual bank embedded program flash

1 MB of SRAM

8 KB I/D Cache + 8 KB System Cache

32-bit SDRAM controller

QuadSPI interface with eXecution-In-Place (XiP)

16-bit SAR ADC: Up to 18ch Single-Ended / 3ch Differential

12-bit DAC

Two analog comparators (CMP) containing a 6-bit DAC and programmable reference input

1.2V Analog voltage reference

One 4 ch-Periodic interrupt timer

Two 16-bit low-power timer PWM modules

Two 8-ch motor control/general purpose/PWM timers

Two 2-ch quadrature decoder/general purpose timers

Real-time clock with independent 3.6 V power domain

Programmable delay block
