Trade Name:DRV3245SQPHPRQ1
Data Manual:DRV3245SQPHPRQ1.pdf
Brand:TI
Particular Year:23+
Package:HTQFP-48
Delivery Date:New and Original
Stock: 2000pcs
The DRV3245SQPHPRQ1 device is a FET gate driver IC for three-phase motor drive applications and is designed to meet the requirements of ISO 26262 for functional safety applications. The device features three half-bridge drivers, each capable of driving both high-side and low-side N-channel MOSFETs, along with advanced FET protection and monitoring. The charge pump drivers achieve 100% duty cycle during cold start operation and support low battery voltages. With integrated current-sense amplifiers, phase comparators, and SPI-based configuration and peripherals, the drivers eliminate most external and passive components, reducing bill of materials and printed circuit board (PCB) space.
The DRV3245SQPHPRQ1 device also integrates diagnostic and protection functions for the internal clock and provides support for common system diagnostic checks, both of which can be instantiated and reported via SPI. The flexibility of this integrated functionality allows the device to be seamlessly integrated into a variety of security architectures.
Features
- Compliant with AEC-Q100 for automotive applications:
- Device temperature class 1:
-40°C to +125°C, TA
- SafeTI™ Semiconductor Components
- Developed to meet the requirements of the ISO 26262 standard
- 4.5V to 45V operating voltage range
- Programmable peak gate drive current up to 1A
- Charge pump gate driver supporting 100% duty cycle
- Shunt amplifier and phase comparator
- A/C devices: 3 shunt amplifiers(1) and three-phase comparator with status via SPI 1
- B devices: 2 shunt amplifiers and three-phase comparators with real-time monitor via digital pins
- S devices: 3 shunt amplifiers
- 3 PWM or 6 PWM input control up to 20kHz
- Capable of single PWM mode commutation
- Supports 3.3V and 5V digital interfaces
- Serial Peripheral Interface (SPI)
- Thermally enhanced 48-pin HTQFP package
- Protection features:
- Internal voltage regulator, battery voltage monitor
- SPI CRC
- Clock monitor
- Analogue built-in self-test
- Programmable dead time control
- MOSFET Breakdown Protection
- MOSFET VDS Overcurrent Monitor
- GATE SOURCE VOLTAGE REAL-TIME MONITOR
- Thermal warning and shutdown
Applications
- 12V Automotive motor control applications
- Electric Power Steering (EPS, EHPS)
- Electric brakes and brake assist
- Transmissions and pumps
Model
Brand
Package
Quantity
Describe
Melexis
QFN32
2000
Intelligent LIN pre-driver for DC motors and brushless DC motors (<2000W)
Maxim
TQFN-32
3000
Quad Smart Serial-Controlled Solenoid and Motor Driver with Advanced Diagnostic
ON
48-LQFP
3690
Sensorless three-phase brushless DC motor controller with gate driver for automotive applications
