CY7C65634-28LTXC is next generation family of high performance, very low power USB 2.0 hub controllers. CY7C65634-28LTXC has integrated upstream and downstream transceivers; a USB Serial Interface Engine; USB Hub Control andRepeater logic; and Transaction Translator logic.

Features

High performance, low-power USB 2.0 Hub, optimized for low cost designs with minimum bll-of-material

USB 2.0 hub controller

Compliant with USB 2.0 specification, TID# 30000060

Up to four downstream ports support

Downstream ports are backward compatible withFS, LS

Single transaction translator (TT) for low cost

Very low power consumption

Supports bus-powered and self-powered modes

Auto switching between bus-powered and self-powered

Single MCU with 2K ROM and 64 byte RAM

Lowest power consumption

Highly integrated solution for reduced BOM cost

Internal regulator - single power supply 5 V required

Provision of connecting 3.3 V with external regulator

Integrated upstream pull-up resistor

Integrated pull-down resistors for all downstream ports

Integrated upstream/downstream termination resistors

Integrated port status indicator control

Internal power failure detection for ESD recovery

Downstream port management

Support individual and ganged mode power management

Overcurrent detection

Two port status indicators per downstream port
