Service Telephone:86-755-83294757
Trade Name:FS150R12N3T7
Data Manual:FS150R12N3T7.pdf
Brand:INFINEON
Particular Year:23+
Package:Module
Delivery Date:New and Original
Stock: 1000pcs
The FS150R12N3T7 is an EasyPACK™ 1B Sixpack IGBT module with TRENCHSTOP™ IGBT7, emitter control 7 diode and NTC technology. This technology significantly reduces losses and provides a high degree of controllability. In contrast to previously used square trench cells, the cell concept is characterised by a parallel trench cell achieved by sub-micron mesh separation. The chip is specifically optimised for use in industrial drive applications and solar systems, which means significantly lower static losses, higher power density and more flexible switching.
Product Properties
IGBT type: Trench field cut-off
Configuration: Three-phase inverter
Voltage - Collector Breakdown (max): 1200 V
Current - Collector (Ic) (max): 150 A
Power - Max: 20 mW
Vce(on) (max) at different Vge, Ic: 1.8V @ 15V, 150A
Current - Collector Cutoff (Max): 12 µA
Input Capacitance (Cies) at varying Vce: 30.1 nF @ 25 V
Input: Standard
NTC Thermistor: Yes
Operating Temperature: -40°C ~ 175°C (TJ)
Mounting Type: Chassis Mount
Package/Housing: Module
Supplier Device Package: AG-ECONO3B
Applications
● Industrial motor drives and controls
● Residential air conditioning - motor-system control and monitoring
● Uninterruptible Power Supplies (UPS)
Model
Brand
Package
Quantity
Describe
ON
MODULE
2000
IGBT Module Trench Field Cutoff Three-Stage Inverter 1200 V 140 A 280 W Chassis Mounting
INFINEON
Module
1000
IGBT Module Single Chopper 1200 V 125 A 400 W Chassis Mount AG-ECONO2B
INFINEON
Module
1000
IGBT Modules Trench Field Cutoff Half Bridge 1200 V 600 A Chassis Mount Modules
INFINEON
Module
1000
IGBT Modules Trench Field Cutoff 2 Standalone 650 V 40 A Chassis Mount Modules
INFINEON
Module
1000
IGBT Module Trench Field Cutoff Half Bridge 1200 V 2400 A 20 mW Chassis Mount Module
INFINEON
Module
1000
IGBT Modules Trench Field Cutoff Full Bridge 1700 V 230 A Chassis Mount Modules
