The TLE9351SJXTMA1 is a high-speed CAN transceiver for use in HS CAN systems in automotive and industrial applications as well as in industrial applications. It is designed to meet the requirements of ISO 11898-2:2016 physical layer specification as well as SAE J1939 and SAE J2284. It is available in a RoHS-compliant, halogen-free PG-DSO-8 package. Serves as an interface between the physical bus layer and the HS CAN protocol controller, protecting the microcontroller from interference generated within the network.

Functional features

● Fully compliant with ISO 11898-2:2016 and SAE J2284-4/-5 standards

● Loop delay symmetry of up to 5 MBit/s for CAN FD data frames

● Certified to VeLIO (Vehicle LAN Interoperability and Optimisation) test requirements

● Extremely low electromagnetic emissions (EME), no additional common mode choke required for use

● Wake-on-Premise (WUP) function with optimised filtering time for global OEM use

● Standby mode with minimised quiescent current

● Excellent ESD robustness

● TxD timeout function

● Extremely low CAN bus leakage current during power down states

● Over-temperature protection

● Automotive transient protection according to ISO 7637 and SAE J2962-2 standards

● Green product (RoHS compliant)

Applications

● Engine Control Units (ECUs)

● Gateway modules

● Body Control Modules (BCM)
