STM32F405RGT6 MCU ARM M4 32-Bit Single-Core 168MHz Microcontrollers IC 64-LQFP

Product Description Of STM32F405RGT6

The STM32F405RGT6 is based on the high-performance Arm®Cortex®-M4 32-bit RISC core operating at a frequency of up to 168 MHz. The Cortex-M4 core features a Floating point unit (FPU) single precision which supports all Arm singleprecision data-processing instructions and data types. It also implements a full set of DSP instructions and a memory protection unit (MPU) which enhances application security.

Specification Of STM32F405RGT6

Speed:168MHz

Connectivity:CANbus, I²C, IrDA, LINbus, SPI, UART/USART, USB OTG

Peripherals:Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT

Number of I/O:51

Program Memory Size:1MB (1M x 8)

Program Memory Type:FLASH

RAM Size:192K x 8

Voltage - Supply (Vcc/Vdd):1.8V ~ 3.6V

Data Converters:A/D 16x12b; D/A 2x12b

Oscillator Type:Internal

Operating Temperature:-40°C ~ 85°C (TA)

Features Of STM32F405RGT6

Clock, reset and supply management

1.8 V to 3.6 V application supply and I/Os

POR, PDR, PVD and BOR

4-to-26 MHz crystal oscillator

Internal 16 MHz factory-trimmed RC (1% accuracy)

32 kHz oscillator for RTC with calibration

Internal 32 kHz RC with calibration

Applications Of STM32F405RGT6

Printers, and scanners

Alarm systems, video intercom, and HVAC

Home audio appliances
