Product Description:

The UE76-A20-3000T ExpressPort® SFP+ connector is designed to significantly reduce impedance discontinuities and reflections at high data rates and reduce near-end crosslink by 10 to 20 dB. The ExpressPort® SFP+ features a unique cage structure that utilizes metal reeds or rubber gaskets for EMI shielding. Additional features are available, including light guides, heat sinks and many other customizable features.

Amphenol ExpressPort® SFP+ interconnect systems offer data transfer rates up to 16Gb/s.

Advantages:

The electrical interface uses one channel to enable PAM4 modulation up to 56Gb/s, providing solutions with total bandwidth up to 56Gb/s

Backward compatible with SFP28

Meets the requirements of CEI-56GPAM4 VSR

Features:

It offers low-cost, ultra-high-speed modular I/O interconnect systems and external I/O products for the networking, telecommunications and storage systems markets

Design

The ventilation hole near the front end is removed to prevent it from being caught by the EMI reed of the connecting module.

The stacked cage is equipped with an integrated high-speed connector

Shielding cage package meets standard SFP connector specification (SFF-8071)

Data rate

Up to 16 Gbps per channel.

Impedance discontinuities and reflections at high data rates are significantly reduced.

Heat dissipation

A radiator option (a passive heat exchanger) is available to transfer heat to the flowing coolant.

Light pipe

The "Connected" or "not connected" status is indicated by an LED mounted on the PCB, which can be purchased with the shield cage or separately.

Applications:

Cellular infrastructure

Network interface card

Data center

Server

To store; reserve

Test and measurement equipment
