ON Memory CAT24C64C4CTR 64 Kb I2C CMOS Serial EEPROM

ON Memory CAT24C64C4CTR 64 Kb I2C CMOS Serial EEPROM

Source:our siteTime:2023-03-02Views:

Mingjiada supplies ON Memory CAT24C64C4CTR 64 Kb I2C CMOS Serial EEPROM, new and original, in stock, price advantage, quality can be guaranteed, interested parties are welcome to contact us！Model: CAT24C64C4CTRBatch number: 16+ Package: WLCSP-4Descri…

Mingjiada supplies ON Memory CAT24C64C4CTR 64 Kb I2C CMOS Serial EEPROM, new and original, in stock, price advantage, quality can be guaranteed, interested parties are welcome to contact us！


Model: CAT24C64C4CTR

Batch number: 16+

Package: WLCSP-4


Description

The CAT24C64 is a 64 Kb CMOS serial EEPROM device, internally organised into 8192 words of 8 bits each. It has a 32 byte page write buffer and supports Standard (100 kHz), Fast (400 kHz) and Fast-Plus (1 MHz) I 2 C protocols. External address pins can address up to 8 CAT24C64 devices on the same bus.


Product properties

Product type: Electrically erasable programmable read-only memory

Mounting style: SMD/SMT

Package / Case: WLCSP-4

Interface type: 2-Wire, I2C

Memory capacity: 64 kbit

Organization: 8 k x 8

Supply voltage - min: 1.7 V

Supply voltage - max: 5.5 V

Min. operating temperature: - 40 C

Max. operating temperature: + 85 C

Max. clock frequency: 1 MHz

Access time: 400 ns

Data retention: 100 years

Supply current - max: 2 mA

Series: CAT24C64

Product Type: EEPROM

Factory Packed Quantity: 5000

Sub Category: Memory & Data Storage
