The Texas Instruments BQ25756RRVR is a self-contained or I²C controlled 70V bi-directional step-down/boost charge controller with MPPT capability.

Instructions:

The BQ25756 is a wide input voltage, switching mode buck/boost Li-ion, Li-polymer or Li-iron phosphate battery charging controller with bi-directional power flow support. The device not only provides accurate charge current and charge voltage regulation, but also provides automatic charge pre-regulation, charge termination and charge status indication, enabling efficient battery charging over a wide voltage range. The device integrates all loop compensation functions of the buck/boost converter, thus providing an easy-to-use high-density solution. In reverse mode, the device draws power from the battery and provides protection by adjusting the input terminal voltage through an added constant current loop, enabling USB-PD EPR power configuration.

In addition to the I2C host controlled charging mode, the device also supports independent charging modes through resistor programmable limits. The input current, charge current, and charge voltage regulation targets can be set via ILIM_HIZ, ICHG, and FB pins, respectively.

Features

• Wide input voltage operating range: 4.2V to 70V

• Wide battery voltage operating range: up to 70V, support multi-compound batteries:

- 1-14 lithium-ion battery charging curve

- 1 to 16 lithium iron phosphate battery charging curve

• Synchronous buck/boost charge controller with NFET driver

- Adjustable switching frequency range: 200kHz to 600kHz

- Synchronize with an external clock

- Integrated loop compensation with soft start

- Optional grid driver power input for increased efficiency

• Automatic Maximum power Point Tracking (MPPT) for solar charging

• Step-down mode only

Bidirectional converter operation (reverse mode) with support for USB-PD Extended Power Range (EPR)

- Adjustable input voltage (VAC) regulation range from 3.3V to 65V with a step size of 20mV

- Adjustable input current regulation (RAC_SNS) with 5mΩ resistors ranging from 400mA to 20A with 50mA step size

• High precision

- ±0.5% charge voltage adjustment

- ±3% charge current adjustment

- The input current adjustment range is ±3%

• With I2C control for excellent system performance with battery programmable options

- Hardware adjustable input and output current limits

• Integrated 16-bit ADC for voltage, current and temperature monitoring

• High security integration

- Adjustable input overvoltage and undervoltage protection

- Battery overvoltage and overcurrent protection

- Charging safety timer

- Battery short-circuit protection

- The hot switch is off

• Status output

- Adapter presence status (PG)

- Charger running status (STAT1, STAT2)

• Encapsulation

- 36 Pin 5mm x 6mm QFN package

Applications

• Kick electric scooters, electric bikes

• Cordless power tools, garden tools

• Lawn mowing robots

• Mobile power station

• Wireless vacuum cleaner, robot vacuum cleaner

• Solar charger

• USB-PD EPR (Extended power range)
