High performance, low power RC22312A000GN1 FemtoClock™ 3 multi-frequency clock synthesizer

High performance, low power RC22312A000GN1 FemtoClock™ 3 multi-frequency clock synthesizer

Source:our siteTime:2024-05-30Views:

Renesas RC22312A000GN1 - FemtoClock™ 3 multi-frequency clock synthesizerOverviewThe RC22312 is an ultra-low phase noise multi-frequency clock synthesizer and numerical control oscillator (DCO). This flexible, low-power device has an output clock with…

Renesas RC22312A000GN1 - FemtoClock™ 3 multi-frequency clock synthesizer


Overview

The RC22312 is an ultra-low phase noise multi-frequency clock synthesizer and numerical control oscillator (DCO). This flexible, low-power device has an output clock with RMS jitter of 25fs and supports 112Gbps and 224Gbps SerDes.


Features

Jitter 25fs RMS, 12kHz to 20Mhz, HPF is 4MHz

Output frequency range:

Differential output is 4kHz to 1GHz

Single-ended output is 4kHz to 250MHz

Up to 12 individual HCSL or LVDS outputs

Integer frequency divider; The differential output can be

Configure two single-ended outputs

DCO frequency resolution < 10-13

Factory programmable internal OTP

12 outputs

9mmX9mm 64-VFQFPN

Operating voltage :1.8V

Serial port supports 1.8V or 3.3V

Working temperature:

Ambient temperature: -40°C to 85°C

Circuit board: -40°C ~ 105°C


Applications

• Clock synthesis for:

- 112Gbps and 224Gbps SerDes

- 100 - g / 200 g / 400 g / 800 g / 1600 GBPS Ethernet physical layer

• Switches and routers

• Medical Imaging

• Test and measurement


Pin diagram
