[ADI] ADUM1401CRWZ Quad-Channel Digital Isolator (3/1 Channel Directionality)

Shenzhen Mingjiada Electronics Co., Ltd. — Long-term supply of ADI (ADUM1401CRWZ) four-channel digital isolators (3/1 channel directionality). Product details are as follows:

Model: ADUM1401CRWZ

Package: SOIC-16

Type: Digital isolator

ADUM1401CRWZ — Product image:

The ADUM1401CRWZ is a four-channel digital isolator featuring 3/1 channel directionality. This device provides four independent isolated channels supporting multiple channel configurations and data rates. Operating from 2.7 V to 5.5 V supply voltages, the ADUM1401CRWZ is compatible with low-voltage systems and enables voltage conversion across the isolation barrier.

ADUM1401CRWZ Specifications:

Technology: Magnetic coupling

Type: General purpose

Isolated power supply: None

Number of channels: 4

Input - Side 1/Side 2: 3/1

Channel type: Unidirectional

Voltage isolation: 2500Vrms

Common-mode transient immunity (minimum): 25kV/µs

Data Rate: 90 Mbps

Propagation Delay tpLH / tpHL (Max): 32 ns, 32 ns

Pulse Width Distortion (Max): 2 ns

Rise/Fall Time (Typ): 2.5 ns, 2.5 ns

Voltage - Supply: 2.7 V to 5.5 V

Operating Temperature: -40°C to 105°C

Mounting Type: Surface Mount

Package/Case: 16-SOIC (0.295", 7.50mm width)

Supplier Device Package: 16-SOIC

ADUM1401CRWZ Applications:

General-purpose multi-channel isolation

SPI interface/data converter isolation

RS-232/RS-422/RS-485 transceivers

Industrial fieldbus isolation

Automotive systems

Mingjiada Electronics maintains long-term supply of ADI (ADUM1401CRWZ) four-channel digital isolators. For further product information or pricing enquiries regarding the ADUM1401CRWZ, please contact Mingjiada Electronics:
