INFINEON Bluetooth Modules CYBT-253059-02 Dual-Mode Bluetooth LE Module

INFINEON Bluetooth Modules CYBT-253059-02 Dual-Mode Bluetooth LE Module

Source:our siteTime:2024-05-24Views:

INFINEON Bluetooth Modules CYBT-253059-02 Dual-Mode Bluetooth LE ModuleProduct DescriptionCYBT-253059-02 is a dual-mode Bluetooth BR/EDR and Low Energy wireless module solution. The CYBT-253059-02 includes an onboard crystal oscillator, passive compon…

INFINEON Bluetooth Modules CYBT-253059-02 Dual-Mode Bluetooth LE Module


Product Description

CYBT-253059-02 is a dual-mode Bluetooth® BR/EDR and Low Energy wireless module solution. The CYBT-253059-02 includes an onboard crystal oscillator, passive components, and the Infineon CYW20820 silicon device. It includes 256 KB of on-chip flash memory and is designed for standalone operation.


Product Features

Module description:

Complies with Bluetooth® Core Specification version 5.0 and includes support for BR, EDR 2/3 Mbps, eSCO, Bluetooth LE, LE 2 Mbps, as well as Bluetooth® Mesh.

Certified to FCC, ISED, MIC, and CE standards

256-KB on-chip Flash, 176-KB on-chip RAM

Industrial temperature range: –30°C to +85°C

Integrated Arm® Cortex®-M4 microprocessor core with floating point unit (FPU)


RF characteristics:

Maximum TX output power: +10.5 dBm

Bluetooth® LE RX Receive Sensitivity: –94.5 dBm


Functional capabilities:

Up to 22 GPIOs

I2C, I2S, UART, and PCM interfaces

Two Quad-SPI interfaces

Auxiliary ADC with up to 15 analog channels

Programmable key scan 20 × 8 matrix

General-purpose timers and six PWMs

Real-time clock (RTC) and watchdog timers (WDT)

Bluetooth® Basic Rate (BR) and Enhanced Data Rate (EDR) support

Bluetooth® LE protocol stack supporting generic access profile (GAP) Central, Peripheral, Observer, or Broadcaster roles
