Shenzhen Recycling Microchip Module MSCSM70AM10CT3AG Recycling Silicon Carbide MOSFET Module

Shenzhen Recycling Microchip Module MSCSM70AM10CT3AG Recycling Silicon Carbide MOSFET Module

Source:our siteTime:2024-05-20Views:

Shenzhen Mingjiada Electronics Recycling Microchip Module MSCSM70AM10CT3AG is a phase pin 700 V/241 A all silicon carbide (SiC) power supply module.Recycled Model: MSCSM70AM10CT3AGManufacturer: MICROCHIPYear: NewVDSS (V): 700RDSon (mR) typ: 7.5Curren……

Shenzhen Mingjiada Electronics Recycling Microchip Module MSCSM70AM10CT3AG is a phase pin 700 V/241 A all silicon carbide (SiC) power supply module.


Recycled Model: MSCSM70AM10CT3AG

Manufacturer: MICROCHIP

Year: New

VDSS (V): 700

RDSon (mR) typ: 7.5

Current (A) Tc=80C: 188

Silicon Type: SiC MOSFET

Package: SP3F


Features

The following are the key features of the MSCSM70AM10CT3AG device:

- SiC Power MOSFET

◦ Low RDS(on)

◦ High speed switching

◦ Ultra-low loss

- SiC Schottky Diode

◦ Zero reverse recovery

◦ Zero forward recovery

◦ Temperature independent switching behaviour

◦ VF positive temperature coefficient

- Very low stray inductance

- Kelvin source for easy driving

- Internal thermistor for temperature monitoring

- Aluminium Nitride (AlN) substrate for improved thermal performance


Advantages

The MSCSM70AM10CT3AG device offers the following advantages:

- High-efficiency converter

- Excellent performance in high-frequency operation

- Direct mounting to heat sink (isolated package)

- Low junction thermal resistance

- Power and signal solder terminals for easy PCB mounting

- Compact form factor

- RoHS compliant


Company website: www.hkmjd.com
