Supply [ON] Original Chips: NCV7424DB0R2G Four Channel LIN Transceiver

Shenzhen Mingjiada Electronics Co., Ltd. — Long-term supplier of Onsemi's NCV7424DB0R2G four-channel LIN transceiver. Below are the detailed specifications of this product:

Product Overview

The NCV7424DB0R2G is a high-performance four-channel LIN (Local Interconnect Network) transceiver developed by Onsemi. It is part of Onsemi's automotive network (IVN) transceiver family. This device is a single-chip solution with performance equivalent to four NCV7321-1 transceivers, primarily used to enable reliable communication between electronic control units (ECUs) within a vehicle.

NCV7424DB0R2G Specifications:

Model: NCV7424DB0R2G

Protocol Support: LIN 2.x, backward compatible with LIN 1.3, SAE J2602

Data Rate: 1 kbps to 20 kbps

Operating Voltage: 5V to 27V (supports 12V/24V automotive systems)

Standby Current: ≤30µA (standby mode)

Operating Temperature: -40°C to +125°C (AEC-Q100 Grade 1)

ESD protection: LIN pins ≥10kV (HBM)

Receiver hysteresis: 100mV

Package type: 16-TSSOP (4.4mm × 5.1mm)

Mounting method: Surface mount

The NCV7424DB0R2G features the following outstanding characteristics, making it particularly suitable for harsh automotive environments:

Multi-channel integration: Single-chip integration of four independent LIN channels, saving PCB space, simplifying system design, and enhancing integration.

High reliability design:

Compliant with AEC-Q100 Grade 1 automotive-grade certification, suitable for harsh automotive electronic environments.

LIN bus pins feature short-circuit protection (for power and ground), load dump protection (45V), and resistance to automotive environment transient interference.

Thermal shutdown functionality prevents chip damage from overheating.

Exceptional EMC performance:

Integrated slope control enables outstanding electromagnetic emission (EME) performance even without capacitors on the LIN pins.

Excellent electromagnetic interference (EMI) performance.

Receiver hysteresis (100mV) enhances noise immunity, ensuring communication stability.

Low power consumption and wake-up functionality:

Extremely low static current in standby mode (typical value ≤30μA), helping to reduce overall system power consumption.

Supports remote wake-up functionality via the LIN bus on all four channels.

Wide voltage compatibility: Wide operating voltage range (5V to 27V), compatible with 12V and 24V automotive systems, and digital interfaces compatible with 3.3V and 5V logic levels.

Application Areas

The NCV7424DB0R2G is primarily used in applications requiring LIN bus communication, particularly:

Automotive Electronics: This is the primary application area for the NCV7424DB0R2G. It is commonly used in body control modules (BCM, such as window, door, and seat control), engine control units, smart sensors, lighting control, etc.

Industrial Automation: It can be used in network communication modules within industrial equipment.

Intelligent Transportation Systems: Such as communication systems between vehicles and infrastructure.

Mingjiada Electronics Supply Information

Quality Assurance: Mingjiada Electronics has a stable and reliable supply chain, strictly controlling the supply chain to ensure the stability and reliability of supplied products.

Adequate Inventory Supply: Mingjiada Electronics maintains sufficient inventory of NCV7424DB0R2G to meet customer needs for both small-batch samples and large-scale procurement.

Fast Delivery: Mingjiada Electronics relies on an efficient logistics system to ensure products are delivered to customers quickly.

【Mingjiada Electronics】Long-term supply of ON (NCV7424DB0R2G) four-channel LIN transceivers. For more information about the NCV7424DB0R2G product or to inquire about pricing, please contact Mingjiada Electronics:
