The ADE-30W is a dual-balanced (RF) mixer produced by Mini-Circuits, mainly applied in the down-conversion scenarios of wireless base stations.
Key features
• Low conversion loss with a typical value of 6.8 dB.
• Excellent L-R isolation with typical values of 35 dB.
• Thin packaging
• Wash with water
Performance parameters
Product: ADE-30W
Radio frequency: 300 MHz to 4 GHz
Conversion loss - maximum: 9.8 dB
LO frequency: 300 MHz to 4 GHz
Medium frequency: 0 Hz to 950 MHz
Maximum operating temperature: + 85 ° C
Minimum operating temperature: -40 ° C
Installation style: SMD/SMT
Packaging/Box: 7.87mm x 5.59mm x 4.11mm
OIP3 - Third-order cut-off point: 12 dBm
Product Type: RF Mixer
Application scenarios
The ADE-30W mixer is suitable for down-conversion in wireless base stations. It achieves efficient frequency conversion through a dual balanced structure and features high isolation, effectively suppressing interference signals.
The ADE-30W mixer is one of the main products of Mingjiada electronics. Welcome to visit www.hkmjd.com to inquire about the purchase quotation.
