Mingjiada Supply STGAP2SCMTR (ST) 4A, Isolated Gate DriversShenzhen Mingjiada Electronics Co., Ltd.——Long term supply of ST (STGAP2SCMTR) 4A Current Isolated Gate Driver.The STGAP2SCMTR is a single gate driver that partially isolates the gate drive…

Mingjiada Supply STGAP2SCMTR (ST)  4A, Isolated Gate Drivers


Shenzhen Mingjiada Electronics Co., Ltd.——Long term supply of ST (STGAP2SCMTR) 4A Current Isolated Gate Driver.


The STGAP2SCMTR is a single gate driver that partially isolates the gate drive channel from the low voltage control and interface circuitry.


The STGAP2SCMTR has a 4A current drive and rail-to-rail output, making the device suitable for high power inverter applications such as motor drives in industrial applications.


Product Details:

Model: STGAP2SCMTR

Package: SOIC-8

Type: Isolated Gate Driver

STGAP2SCMTR Product Diagram:

STGAP2SCMTR 老.jpg


STGAP2SCMTR Product Attributes:

Technology: Magnetically Coupled

Number of Channels: 1

Voltage - Isolated: 1700VDC

Common Mode Transient Immunity (min.): 100V/ns

Propagation Delay tpLH / tpHL (max.): 100ns, 100ns

Pulse Width Distortion (max.): 20ns

Rise/Fall Time (typical): 30ns, 30ns

Current - Outputs High, Low: 4A, 4A

Voltage - Output Supply: 3V ~ 5.5V

Operating Temperature: -40°C ~ 125°C (TJ)

Mounting Type: Surface Mount

Package/Case: 8-SOIC (0.154", 3.90mm wide)


STGAP2SCMTR Configurations with separate output pins can be independently optimised for on-state and off-state using gate resistors. Configurations with a single output pin and Miller clamp function prevent gate spikes during fast commutation in half-bridge topologies.


The STGAP2SCMTR has integrated protection features: including UVLO and thermal shutdown, making it easy to design high-reliability systems. Dual input pins allow selection of control signal polarity and hardware interlock protection from conduction in case of main controller failure.
