[TI] TPS7A8500RGRR Low-Noise (4.4 µVRMS), Low-Dropout Linear Regulator (LDO)

Shenzhen Mingjiada Electronics Co., Ltd. — Long-term supplier of TI TPS7A8500RGRR high-performance, low-noise, low-dropout linear regulator (LDO)

Product Core Description

The TPS7A8500RGRR is a high-performance, ultra-low-noise, high-current LDO regulator. It employs advanced manufacturing processes and design to deliver an impressive 4.4 µVRMS ultra-low output noise (10 Hz to 100 kHz) and excellent power supply ripple rejection ratio (PSRR) while providing up to 5A output current.

TPS7A8500RGRR Product Features

Ultra-Low Noise: With only 4.4 µVRMS of wide-band noise, it significantly reduces interference with high-precision analogue circuits (such as ADCs, DACs, PLLs, VCOs, and sensors) and RF circuits (such as local oscillators (LOs)). This is the core competitive advantage of the TPS7A8500RGRR.

High Current & Low Dropout: Maximum output current of 5A with extremely low dropout voltage (typical value) at full load, effectively improving power conversion efficiency, especially when the input voltage is close to the output voltage, thereby extending the runtime of battery-powered devices.

Excellent PSRR (High PSRR): Provides outstanding power supply ripple suppression capability across a wide frequency range (e.g., >70dB at 1kHz), effectively filtering out noise and ripple from upstream switching power supplies or batteries, providing a ‘quiet’ voltage to the load.

High Accuracy and Flexibility: High output voltage accuracy (±1% typical value), with flexible adjustment via an external resistor within the range of 0.8V to 5.2V to meet the needs of different circuits.

Comprehensive Protection: Integrated overcurrent protection (OCP), over-temperature shutdown (TSD), and enable (EN) control functions ensure system and device safety and reliability.

Compact Package: Utilises a 20-pin VQFN (RGR) package.

TPS7A8500RGRR Key Specifications

Input Voltage Range (VIN): 3.0 V to 17.0 V

Output Voltage Range (VOUT): 0.8 V to 5.2 V (adjustable)

Output Current (IOUT): Up to 5 A (continuous)

Output Noise: 4.4 µVRMS (typical, 10 Hz to 100 kHz, VOUT = 5.0 V)

Dropout Voltage: Extremely low

Power Supply Rejection Ratio (PSRR): >70 dB (typical, f = 1 kHz, VOUT = 5.0 V)

Output Voltage Accuracy: ±1% (typical)

Operating Junction Temperature Range (TJ): -40°C to +125°C

Package: 20-pin VQFN (3.5mm x 5.5mm - RGR)

Typical Application Areas for the TPS7A8500RGRR

The TPS7A8500RGRR's ultra-low noise and high-performance characteristics make it an excellent choice for the following precision electronic systems:

Digital loads: serial-to-parallel converters, field-programmable gate arrays (FPGAs), and digital signal processors (DSPs)

Instrumentation, medical, and audio

High-speed analogue circuits:

Voltage-controlled oscillators (VCOs), analogue-to-digital converters (ADCs), digital-to-analogue converters (DACs), and low-voltage differential signalling (LVDS)

Imaging: Complementary metal-oxide-semiconductor (CMOS) sensors and video application-specific integrated circuits (ASICs)

Test and measurement

【Mingjiada Electronics】Long-term supply of TI (TPS7A8500RGRR) 4A, low input voltage, low noise, high precision, ultra-low dropout voltage regulator with power normal indication function. For more information about the TPS7A8500RGRR product, please contact Mingjiada Electronics:
