The AR0237SRSC12SHRA0-DR is a 1/2.7-inch CMOS digital image sensor with an effective pixel array of 1928 (H) × 1088 (V). The AR0237SRSC12SHRA0-DR features a rolling shutter reading and supports both linear and high dynamic range modes. It is suitable for low-light and high dynamic range scenarios.

Its main characteristics

The AR0237SRSC12SHRA0-DR features DR-PIX™ technology with dual conversion gain

Full HD support up to 1080p at 60 fps enables outstanding video performance

Linear or high dynamic range capture

On-chip phase-locked loop (PLL) oscillator

Support line interlaced T1/T2 readout to achieve HDR processing in the ISP chip

Integrate location-based color and lens shadow correction

Subordinate mode for precise frame rate control

Support for stereoscopic /3D cameras

Statistical engine

Four-channel Serial High-Speed Pixel Interface (HiSPi)

Automatic black level calibration

High-speed configurable context switching

Temperature sensor

Details of AR0237SR

The AR0237SRSC12SHRA0-DR is a 1/2.7-inch CMOS digital image sensor with an effective pixel array of 1928 (H) × 1088 (V). It can capture images in linear or high dynamic range modes and features a rolling shutter read, which includes complex camera functions such as pixel loading, windowing, and video and single-frame modes. The AR0237SRSC12SHRA0-DR is suitable for low luminosity and high dynamic range scene performance and can be programmed through a simple two-wire serial interface. The AR0237SRSC12SHRA0-DR can generate extremely clear and sharp digital images, and is capable of simultaneously capturing continuous video and single-frame images. It is suitable for a variety of applications such as surveillance and high-definition video.

Application field

The AR0237SRSC12SHRA0-DR is suitable for a variety of application scenarios, including:

Video surveillance

1080p60 (surveillance) video application

High dynamic range imaging

Surveillance camera

Basic parameters

Product: AR0237SRSC12SHRA0-DR

Type: CMOS

Pixel size: 3µm x 3µm

Active pixel array: 1928H x 1088V

Frames per second: 60.0

Voltage - Power supply: -

Package/Shell: 48-LCC

Supplier device packaging: 48-mPLCC (11.43x11.43)

For exclusive quotations of AR0237SRSC12SHRA0-DR, please visit the official website of Mingjia Da (www.hkmjd.com).
