[Supply] Original Chip TPA3100D2PHP (TI) 20W Stereo Class D Audio Power Amplifier

Shenzhen Mingjiada Electronics Co., Ltd. is a long term supplier of TI (TPA3100D2PHP) 20W stereo, analogue input Class D audio amplifier.

Product Details:

Model: TPA3100D2PHP

Package: HTQFP-48

Type: Class D Audio Amplifier

Application: Television

TPA3100D2PHP Product Diagram:

The TPA3100D2PHP is a 20 W (per channel) high-efficiency Class D audio power amplifier for driving bridged stereo speakers.The TPA3100D2PHP is up to 92% efficient, eliminating the need for an external heat sink when playing music. The outputs feature an auto-recovery function and monitor outputs for complete protection against ground shorts, VCC shorts, and output-to-output shorts.

TPA3100D2PHP Specifications:

Type: Class D

Output Type: 2-channel (Stereo)

Maximum Output Power x No. of Channels at Various Loads: 21.8W x 2 @ 8 Ohms

Voltage - Supply: 10V ~ 26V

Features: differential inputs, mute, short-circuit and thermal protections, shutdown

Mounting Type: Surface-Mount

Operating Temperature: -40°C ~ 85°C (TA)

Package/Case: 48-HTQFP (7x7)

TPA3100D2PHP Product Features:

20W/ch to 8Ω load (18V power supply)

10W/ch to 8Ω load (12V power supply)

15W/ch to 4Ω load (12V power supply)

Operating voltage range of 10V to 26V

92% efficient Class D operation, no heat sink required

Four selectable fixed gain settings: 20, 26, 32, and 36 dB

Differential inputs

Thermal Thermal and short-circuit protection with auto-recovery

Clock output for synchronisation with multiple Class D devices

Surface-mount 9 mm × 9 mm, 48-pin HTQFP package
