[Original Chips] ADL5506ACBZ (ADI) 30MHz To 4.5GHz, 45dB RF Detector

Shenzhen Mingjiada Electronics Co., Ltd.——Long-term supply of ADI (ADL5506ACBZ) for RF signal measurement in the frequency range of 30 MHz to 4.5 GHz, with a typical dynamic range of 45 dB, mainly used in a variety of wireless terminal equipment.

Product Details:

Model: ADL5506ACBZ

Package: WLCSP-6

Type: RF Signal Measurement - RF Detector

Product Diagram:

The ADL5506ACBZ is available in a 6-pin WLCSP package and consumes 3.8 mA at a supply voltage of 3.0 V. Typical disable current is less than 1 µA when switched off. It offers a wider dynamic range and higher accuracy than discrete diode-detector solutions, with particularly good temperature stability over the -40°C to +85°C temperature range. temperature stability over the -40°C to +85°C temperature range.

ADL5506ACBZ Specifications:

Frequency: 30MHz ~ 4.5GHz

RF Type: General Purpose

Input Range: -45dBm ~ 5dBm

Accuracy: ±1dB

Voltage - Supplied: 2.5V ~ 5.5V

Current - Supplied: 3.8 mA

Mounting Type: Surface Mount

Package/Housing: 6-XFBGA, WLCSP

Vendor Device Packages: 6-XFBGA, WLCSP (0.76x0.5V), WLCSP (0.76x1.5V), WLCSP (0.76x1.5V) WLCSP (0.76x1.36)

ADL5506ACBZ Applications:

RSSI and TSSI for Wireless End Devices

RF Transmitter or Receiver Power Measurement

Automotive RF Bidirectional Amplifier

[ADL5506ACBZ RF Detector] A complete low-cost subsystem with high sensitivity that allows measurements to be made at lower power levels, thus reducing the power consumption required for coupling to the detector. The device is essentially a voltage responsive device with a typical dynamic range of 45 dB.

【Mingjiada Electronics】Long-term supply of ADI (ADL5506ACBZ) RF detector, for more information about ADL5506ACBZ products or purchase samples, welcome to contact Mingjiaoda Electronics:
