Product introduction

The RH850/U2A area/Domain microcontroller is an automotive control device designed to meet the growing demand for unified electronic control units (ECUs) that integrate multiple applications into a single chip to enable evolving electronic (E/E) architectures.

With 28 nm process technology, the 32-bit R7F702Z19BFDBG MCU is based on key features of Renesas RH850/Px series chassis control and RH850/Fx series body control to improve performance.

The automotive control MCU is equipped with four 400MHz CPU cores and adopts a dual-core lock-step structure. Each CPU core integrates hardware-based virtualization assistance, allowing multiple software systems with different ISO26262 functional security levels to operate independently without interference during high performance. Virtualization AIDS also reduce virtualization overhead to maintain real-time execution. This enables users to integrate multiple ECU functions into a single ECU while maintaining safety, security, and real-time operational requirements.

Features

400MHz speed for up to 4+4 (lock step) RH850 G4MH CPU

Maximum performance to power ratio

Up to 16MB flash memory

Up to 3.6MB RAM

Up to 3 ADCs (12 bits) with up to 94 channels, including 4 + 4 tracking to hold input

GTM v3.5 Vehicle motion timer

Various general purpose timer modules, including watchdog, operating system and TAUx

High temperature support (Tj up to +160°C)

Low power consumption

port

Up to 2 Ethernet AVBs, including gigabits and 100MB

CAN-FD, FlexRay, SPI, RHSIF, SENT, LIN, UART, I2C, PSI5, and CXPI

SFMA (Serial Flash Interface)

eMMC

Support for FuSa and security

Full support for EVITA security modules

ISO26262 ASIL D

Extensive ecosystem that supports the latest standards in tools, hardware and software

Hypervisor support

Applications

• Area control ECU

• Domain control ECU

• Communication gateway

• Chassis and safety

• Energy tube
