Shenzhen Mingjiada Electronics Co., Ltd.Supply [ADI] ADUM6028-5WBRIZ Isolated Module DC Converter 4.5V - 5.5V Input

Product Description:

The ADUM6028-5WBRIZ uses ADI's iCoupler® technology to provide a regulated isolated power supply that is below the CISPR22 Class B limits pertaining to 2-layer printed circuit boards (PCBs) with ferrites at full load. Tables 1 to 4 in the datasheet list common voltage combinations and their associated current output levels. There is no need to design and build isolated DC/DC converters for applications up to 500mW. iCoupler chip-scale transformer technology is used for the magnetic components of the DC/DC converter. This provides a small footprint, isolated solution.

Features

isoPower Integrated Isolated DC-DC Converter

ADuM6020 has an output current of 100 mA

ADuM6028 with 60 mA output current

AEC-Q100 certified for automotive applications

Compliant with CISPR22 Class B emission limits PCB at full load on a 2-layer PCB

16-lead SOIC_IC package with 8.3 mm minimum creepage distance

8-lead SOIC_IC package with minimum creepage distance of 8.3 mm

High-temperature operation: Up to 125°C

UL Listed: 5000 V rms for 1 minute according to UL 1577

CSA certification: Complies with IEC 62368-1, IEC 61010-1, and IEC 60601-1.

60601-1

TÜV SÜD certified according to EN IEC 62368-1

VDE V 0884-10

VIORM = 565 V peak

CQC certified according to GB4943.1-2011

Applications: RS-485/RS-422/CS-422

RS-485/RS-422/CAN transceiver power supplies

Startup bias and gate drive power supplies

Isolated sensor interfaces

Automotive On-Board Chargers (OBC) and DC to DC

Industrial PLCs
