[Supply TI Gate Drivers] Supply UCC27523DR Dual-Channel Low-Side Gate Driver IC

Shenzhen Mingjiada Electronics Co., Ltd.——Long term supply of TI (UCC27523DR) 5A/5A Dual Gate Driver with 5V UVLO, Inverting Inputs and Enable Function.

Below are the product details for the low side driver (UCC27523DR):

The UCC27523DR is a dual-channel, high-speed, low-side gate driver capable of efficiently driving MOSFET and IGBT power switches. Designed to minimise breakdown current, the device delivers high peak current pulses of up to 5A pull and 5A sink for capacitive loads, while achieving rail-to-rail drive capability and ultra-short propagation delays (typically 13ns).

Part Number: UCC27523DR

Package: SOIC-8

Type: Low Side Gate Driver

Product Diagram:

UCC27523DR Product Features:

Two independent gate drive channels

5A peak pull and sink currents

Independent enable function for each output

TTL and CMOS compatible logic thresholds (supply voltage independent)

Hysteresis logic thresholds for high noise immunity

Input and enable pin voltage levels not limited by VDD pin auxiliary supply voltage

4.5V to 18V single supply voltage range

Outputs held low during VDD undervoltage lockout (UVLO) (ensures interference-free operation during power-up and power-down)

Short propagation delay (13ns typical)

Fast rise and fall times (7ns and 6ns typical, respectively)

1ns typical for delay matching between two channels

Two outputs in parallel for higher drive current

Outputs are held low when inputs are dangling

Operating temperature range of -40°C to 140°C

UCC27523DR application area:

Switch-mode power supplies

DC/DC converters

Motor Control, Solar

Gate drive for new-to-market wide-bandgap power devices such as GaNs

The Texas Instruments (TI) UCC27523DR is a high-performance, dual-channel, low-side gate driver designed to drive power switching devices such as MOSFETs and IGBTs. With strong supply chain capability, Mingjiada Electronics has been providing UCC27523DR high-speed, low-side gate drivers to customers for a long time. For more information about UCC27523DR or to purchase samples, please contact Mingjiada Electronics.
