As a professional electronic components supplier, Mingjiada Electronics has been supplying Infineon's new generation of high-speed CAN transceiver TLE9250SJ in stock for a long time, which is a high-performance CAN bus interface chip specially designed for automotive electronics and industrial applications, and fully complies with ISO 11898-2(2016) standard, supporting CAN FD data frame transmission, with a maximum rate of up to 5Mbps. up to 5Mbps.

TLE9250SJ Product Overview

The TLE9250SJ is Infineon's latest generation of high-speed CAN (Controller Area Network) transceivers, which play a key role in automotive and industrial CAN networks as an interface between the physical layer and the CAN protocol controller. The device features Infineon's advanced Smart Power Technology (SPT) with very high ESD protection and excellent electromagnetic compatibility (EMC) performance.

The TLE9250SJ is available in a standard PG-DSO-8 package (8-pin SOIC package) with compact dimensions for space-constrained application scenarios. With a wide operating temperature range of -40°C to 150°C, the device fully meets the harsh environmental requirements of automotive electronics. All TLE9250SJs are guaranteed to be genuine Infineon products, with full technical support and after-sales service.

As a key component of the CAN bus system, the TLE9250SJ effectively protects the microcontroller from network interference. Its highly symmetrical CANH and CANL output signals significantly reduce electromagnetic emissions (EME) and maintain extremely low interference levels over a wide frequency range. This makes the TLE9250SJ ideal for modern automotive electronic systems and industrial CAN networks.

TLE9250SJ Key Features

Standards Compatibility: Fully compliant with ISO 11898-2 (2016) and SAE J2284-4/-5 standards.

High-speed data transmission: Supports CAN FD data frames up to 5 Mbit/s.

Low Electromagnetic Emission: Extremely low Electromagnetic Emission (EME), no additional common mode choke required.

High ESD protection: Excellent electrostatic discharge (ESD) robustness to ±8kV (HBM) and ±11kV (IEC 61000-4-2).

Multiple Protection Functions: Including over-temperature protection, output current limiting, TxD timeout function, etc.

Multiple operating modes: supports receive-only mode and power-saving mode.

Various package options: Standard PG-DSO-8 package and small pinless PG-TSON-8 package are available, the latter supports automatic optical inspection (AOI).

TLE9250SJ Specifications

Electrical Parameters:

Operating voltage: 4.5V~5.5V

Operating Current: 38mA

Data rate: up to 5 Mbit/s

Receiver hysteresis: 100mV

Operating conditions:

Operating temperature: -40°C~+150°C

Storage temperature: -55°C~+150°C

Mechanical parameters:

Package: PG-DSO-8

Number of pins: 8 pins

Product Application

The TLE9250SJ is suitable for a wide range of automotive and industrial applications, including but not limited to:

Automotive applications:

Engine Control Units (ECUs)

Electric Power Steering (EPS)

Transmission Control Units (TCUs)

Chassis control modules

Industrial Applications:

Industrial automation equipment

Building automation systems

Medical equipment

For more information about the TLE9250SJ or to receive a quote, please contact the sales team at Mingjiada Electronics. We will provide you with professional and efficient service to meet all your needs for high speed CAN transceivers.
