Shenzhen Mingjiada Electronics Co., Ltd. recycled and sold TI TPS62135RGXR high-precision 3V to 17V, 4A buck converter (TPS62135).

Product overview

The TPS62135 buck converter is a synchronous buck DC-DC converter based on the DCS-Control™ topology that is not only efficient but also easy to use. The device has a wide input voltage range of 3V to 17V, making it suitable for use in multiple lithium batteries and 12V intermediate power rail applications. Each device provides 3.5A continuous output current. The TPS62135 automatically enters energy saving mode at light loads, thus maintaining high efficiency over the entire load range. As a result, these devices are well suited for applications that require networked standby performance, such as ultra-low power computers.

With the MODE pin set to low level, the switching frequency of the device is automatically adjusted according to the input and output voltages. This technology, known as Automatic Efficiency Enhancement (AEE™), maintains high conversion efficiency across the entire range of work. It provides 1% output voltage accuracy in PWM mode, thus ensuring that the design of the power supply maintains high output voltage accuracy.

Applications

• Standard 12V power rail

• POL that meets networking standby requirements

• POL power supply consisting of single or multi-cell lithium-ion batteries

• Game consoles, SSDS

• Mobile and embedded computers

Features

• Output voltage accuracy ±1% (PWM mode)

• Input voltage range: 3V to 17V

• Static current 18µA (typical)

• Output voltage range from 0.8V to 12V

• Adjustable soft start

• Force PWM or PWM/PFM operation

• A typical switching frequency of 2.5MHz under forced PWM operation

• Precision enable input is possible

- User-defined undervoltage lock

- Accurate sorting

• 100% duty cycle mode

• Automatic efficiency enhancement AEE™

• DCS-Control™ topology

• Can be used for active output discharge

• Optional HICCUP overcurrent protection

• Normal power output

• Available in 3mm x 2mm VQFN package
