[Distribution IGBT transistors] IKW25N120CS7 and IKW25N120CS7XKSA1 are available in TO-247 package

[Distribution IGBT transistors] IKW25N120CS7 and IKW25N120CS7XKSA1 are available in TO-247 package

Source:our siteTime:2024-01-02Views:

Shenzhen Mingjiada Electronics Co., Ltd. new and original [Distribution IGBT transistors] IKW25N120CS7 and IKW25N120CS7XKSA1 1200 V/25 A IGBT7 S7 in TO-247 package with anti-parallel diode.IKW25N120CS7 Device Description1200 V/25 A TRENCHSTOP™ IGBT7 …

Shenzhen Mingjiada Electronics Co., Ltd. new and original [Distribution IGBT transistors] IKW25N120CS7 and IKW25N120CS7XKSA1 1200 V/25 A IGBT7 S7 in TO-247 package with anti-parallel diode.


IKW25N120CS7 Device Description

1200 V/25 A TRENCHSTOP™ IGBT7 S7 single tube for hard switching in TO-247 package with EC7 diode. It features a low VCEsat for very low conduction losses in the target application, while its very soft fast diode helps to minimise switching losses, thus reducing overall losses.


Feature Description

Very low VCEsat

Excellent controllability

Full-current continuity diode with increased softness

Very rugged, withstands harsh conditions and passes HV-H3TRB test

Short circuit time: 8 us

Low deviation of parameter distribution

Maximum operating junction temperature: 175°C


Advantages

Higher power output due to lower IGBT losses and higher system efficiency

Increased power density eliminates the need to redesign heat sinks

Easily and conveniently replaces the previous generation of the T2 product family

High device reliability, even under harsh operating conditions

Easily designed to easily meet EMI requirements


Application Areas

Uninterruptible Power Supplies (UPS)

Motor control and drives


For more information, please call Mr Chen:

Tel: +86 13410018555

Email: sales@szmjd.com

Website: www.hkmjd.com
