Infineon Technologies expands its XDP digital protection product line with the XDP711-001. This is a digital hot-swappable controller with a wide input voltage range of 48 V, programmable safe Operating area (SOA) control and designed for high-power AI servers. The controller has excellent input and output voltage monitoring and reporting functions with an accuracy of ≤0.4%, as well as system input current monitoring and reporting functions with an accuracy of ≤0.75% across the ADC range, which can improve the system's fault detection and reporting accuracy.

The XDP711-001 hot-swap controller uses pulsed SOA current control technology to enable safer on-off even in systems without optimal field-effect transistors (FETs), thereby reducing system material (BOM) costs. This new addition to the XDP product family is designed to drive multiple MOSFETs in parallel, supporting the critical requirement of high power design for this AI server.

The XDP711-001 uses a three-block architecture that combines high-precision telemetry for monitoring and fault detection, digital SOA control optimized for power MOSFETs, and a high-current integrated driver capable of driving up to eight N-type power MOSFETs. Support 4 kW, 6 kW and 8 kW power transfer board (PDB) design. The new hot-swap controller operates over a wide input voltage range from 7 V to 80 V and can withstand transient voltages up to 100 V for up to 500 ms, providing input power monitoring and reporting with ≤1.15% accuracy. It has active monitoring function compatible with high-speed PMBus to improve system reliability. In severe overcurrent (SOC) situations, the programmable gate shutdown function can perform the shutdown operation quickly and reliably in as little as 1 microsecond. Additional features include IMON, PMON, and surge immunity to further improve system availability. In addition, the all-digital mode of operation significantly reduces the need for external components, enabling a compact solution that makes it cost-effective in space-constrained designs.

With external FET selection and one-time programmable (OTP) options, the XDP711-001 provides flexibility for fault and warning detection and programming of de-jitter (de-glicth) timers for a variety of usage modes. The Analog Assisted Digital Mode (AADM) is backward compatible with traditional analog hot swap controllers.

Magdalene Boebel, vice president of IC product line at Infineon Technologies, said: "Infineon's XDP711-001 hot-swapable controller, with its feature rich, high-precision analog front end, as well as comprehensive health monitoring, telemetry, programmability, and preset MOSFET SOA, will be well positioned to meet the challenges of today's pluggable AI server solution design." The power and adaptability of the XDP711-001 demonstrate Infineon's relentless pursuit of innovation, setting a new benchmark in system reliability for AI servers and other applications such as network routers and switches."

The controller is paired with Infineon's OptiMOS and OptiMOS LinearFET portfolio to provide reliable and powerful system performance.

availability

The XDP711-001 Hot Swap and System Monitoring controller IC is available in a VQFN-29 6mm x 6mm package and will be available for order from mid-2025. For details, please refer to www.infineon.com/protection-and-monitoring-ics.
