Overview

The MAX25210ATAB8U High voltage linear regulator series is ideal for use in automotive and battery powered systems. Powered by +3.5V to +30V input voltages, the device provides up to 300mA of load current with a static current consumption of only 10µA (typical) when unloaded. The MAX25210ATAB8U has a current consumption of only 2µA (typical) when turned off. The input has a +42V transient tolerance to operate under sudden load drops. The MAX25210ATAB8U can be configured with a fixed output voltage (+3.3V or +5V) or with an adjustable output voltage using an external resistor divider.

The MAX25210ATAB8U has an open-leak, low-level active RESET output that provides 93.5% and 87.5% of the output voltage as fixed thresholds. After the output voltage exceeds its threshold, the low-level active RESET output will remain low for a fixed period of 60μs. The MAX25210ATAB8U can be extended with an external capacitor for low level active RESET delay.

Core advantage

1, wide input voltage range ‌ :

The MAX25210ATAB8U supports +3.5V to +30V input voltage, suitable for 12V/24V automotive electrical systems and multi-type battery power supply scenarios ‌.

‌2, high efficiency and low power consumption ‌ :

The MAX25210ATAB8U offers up to 300mA of load current, only 10μA (typical) at rest when unloaded, and as low as 2μA in shutdown mode ‌.

The MAX25210ATAB8U supports fixed output voltage (+3.3V or +5V) or adjustable output voltage by external resistance divider for flexible design ‌.

3. High reliability protection mechanism ‌ :

Integrated enable input, short circuit protection and thermal shutdown functions to ensure the MAX25210ATAB8U safe operation under overcurrent and overtemperature conditions ‌.

Operating temperature ranges from -40°C to +125°C, the MAX25210ATAB8U complies with AEC-Q100 vehicle specification standard ‌.

4, compact package design ‌ :

The MAX25210ATAB8U is available in a heat-resistant enhanced 3mm x 3mm 8-pin TDFN package for space-constrained automotive electronics modules ‌.

Typical application scenario

1. Automotive electronic system ‌ :

ADAS sensor power supply ‌ : MAX25210ATAB8U provides stable low-voltage power supply for ADAS modules such as cameras and radars, with strong anti-interference capability ‌.

Vehicle infotainment system ‌ : MAX25210ATAB8U optimizes standby power consumption through low static current and prolongates battery life ‌.

2. Battery powered equipment ‌ :

In industrial handheld terminals and portable medical devices, the MAX25210ATAB8U supports multiple lithium batteries or ultracapacitors with a wide input range ‌.

In smart wearable devices, the MAX25210ATAB8U's small size package and high efficiency features help extend battery life ‌.
