Shenzhen Mingjiada Electronics Co., LTD. (recycled) (sold) RF amplifier, F2480NBGI8 broadband RF analog VGA, 400MHz to 3000MHz.

Product Details:

The F2480NBGI8 is a 400 to 3000 MHz RF analog variable gain amplifier (AVGA) that can be used in receivers, transmitters and other applications. An amplifier or voltage variable attenuator (VVA) can be configured as the first stage in the cascade. The F2480 RF AVGA offers a typical maximum cascade gain of 12dB (without attenuation), a 4.3dB noise figure (with the amplifier as the first stage), and 36dB gain adjustment, and is designed to be powered by a single +5V supply. When using the 106mA ICC, the Zero-Distortion™ amplifier has a nominal output IP3 of +41.5dBm. The device comes in a 5 X 5 mm, 32-TQFN package with 50Ω single-ended RF input and RF output impedance for easy integration into the signal path family.

Typical applications:

Multi-mode, multi-carrier receiver

PCS1900 base station

DCS1800 base station

WiMAX and LTE base stations

UMTS/WCDMA 3G base station

PHS/PAS base station

Peer-to-peer infrastructure

Public safety infrastructure

Wide-band repeater

GPS receiver

Distributed antenna system

Cable infrastructure

Digital radio

Product features:

400 to 3000 MHz (amplifier range)

50 to 6000 MHz (Attenuator range)

12dB (typical cascade maximum gain)

36dB continuous gain range

Excellent linearity +41.5dBm OIP3

Noise factor 4.3dB

ICC=106mA

1.2mA amplifier standby current

Two-way attenuator RF port

Positive amplifier gain slope is offset with frequency

System PCB loss.

The VMODE pin supports a positive or negative attenuation control response

Linear dB attenuation characteristics

Four RF port pin arrays support a variety of configurations

50Ω input and output impedance

Broadband, internal matching

5 X 5 mm, 32 pin TQFN package
