TMM-106-01-S-D-SM-P-TR: Parameters, features and applications of the high-performance connector

The TMM-106-01-S-D-SM-P-TR is a high-performance, thin and lightweight Tiger Eye™ plug connector from Samtec, which is widely used for board-to-board connections in electronic devices. The following are the detailed parameters, features and applications of TMM-106-01-S-D-SM-P-TR:

1.Product Parameters

Number of pins and rows: TMM-106-01-S-D-SM-P-TR is a 12-pin double-row design.

Pitch: The pin pitch is 2.00mm (0.079 inches), which is suitable for high-density wiring.

Current Rating: Up to 3.2A per pin.

Voltage rating: 250VAC to 281VAC when used with specific sockets.

Mounting: Surface Mount Technology (SMT) for automated production.

Insulation Material: Black liquid crystal polymer (LCP) for good electrical performance.

Operating temperature range: -55°C to +105°C (tin plated) or -55°C to +125°C (gold plated).

2.Product Features

Low-profile design: TMM-106-01-S-D-SM-P-TR has a low-profile structure that saves space and is suitable for compact devices.

High reliability: The pin material is phosphor bronze with gold or tin plated surface to ensure good contact performance.

Flexible Configuration: Supports a variety of pin count and row configurations up to 200 pins.

Strong compatibility: Compatible with a variety of Samtec series sockets, such as SQT, SQW, ESQT and so on.

Environmental characteristics: RoHS compliant, lead-free solderable.

3.Application Scenario

TMM-106-01-S-D-SM-P-TR is suitable for board-to-board connection of many kinds of electronic equipments, typical application scenarios include:

Communication equipment: for internal connection of base stations, routers and other equipment.

Industrial automation: to provide high-density connections in devices such as PLC controllers, sensor modules, etc.

Consumer electronics: for internal component connections in devices such as tablet PCs, smart watches, etc.

Automotive electronics: for internal connections in automotive electronic control units (ECUs).

4.Mingjiada's supply advantages

Shenzhen Mingjiada Electronics Co., Ltd. is a professional electronic components distributor, long-term supply of TMM-106-01-S-D-SM-P-TR. Mingjiada can provide customers with original high-quality products with its rich inventory resources and strict quality control. In addition, Mingjiada also provides professional one-stop service to meet the needs of different customers.

With its high performance, high reliability and flexible configuration, TMM-106-01-S-D-SM-P-TR is the ideal choice for electronic equipment connection. And Mingjiada Electronics, as its supplier, is able to provide customers with stable and efficient product support.
