Mingjiada——Supply [NXP] LPC11E68JBD48 32-Bit Microcontroller Based On ARM Cortex-M0+ Core

Shenzhen Mingjiada Electronics Co., Ltd. has been supplying LPC11E68JBD48 microcontroller (MCU) for a long time, and we have a solid and reliable supply channel to ensure the stability and reliability of product supply. Here is the detailed description for NXP LPC11E68JBD48 Entry Level 32-bit Microcontroller (MCU):

Basic Information:

Model: LPC11E68JBD48

Package: LQFP-48

Package size: 7mm x 7mm

Type: 32-bit Microcontroller MCU

Overview

The NXP LPC11E68JBD48 is a 32-bit microcontroller based on the ARM Cortex-M0+ core designed for low-power, high-performance embedded applications.The LPC11E68JBD48 integrates a rich set of peripherals and memory resources for use in industrial control, consumer electronics, the Internet of Things (IoT), and the smart home.

Core features of the LPC11E68JBD48:

LPC11E68JBD48 - High-performance core:

ARM Cortex-M0+ core running at up to 50 MHz.

Supports Thumb-2 instruction set for high code density and performance.

Single-cycle multiplier and hardware divider for improved computational efficiency.

LPC11E68JBD48 - Memory resources:

128 KB Flash memory for program storage.

16 KB SRAM for data storage and operation.

4 KB EEPROM, emulates EEPROM functionality for non-volatile data storage.

LPC11E68JBD48 - Low power design:

Operating voltage range: 1.8V to 3.6V.

The LPC11E68JBD48 supports multiple low-power modes, including:

Sleep mode

Deep-sleep mode

Power-down mode

Deep power-down mode

LPC11E68JBD48 - Typical power consumption:

Running mode: approximately 100 µA/MHz.

Deep-sleep mode: as low as 1.5 µA.

LPC11E68JBD48 - Rich peripheral interfaces:

Communication interfaces:

2 x UART

2 x SPI

1 x I2C

1 x SSP (Synchronous Serial Port)

Analogue peripherals:

12-bit ADC, supports 8 channels, sampling rate up to 1.2 MSPS.

Timers:

4 x 32-bit timers

1 x 24-bit System Timer (SysTick)

1 x Window Watchdog Timer (WWDT)

1 x Real Time Clock (RTC)

PWM: Supports 4-channel PWM output.

GPIO: Up to 42 general-purpose I/O pins.

LPC11E68JBD48 - Benefits:

Cost-effective: Provides high performance and rich peripherals for cost-sensitive applications.

Low power consumption: Multiple low-power modes for battery-powered devices.

Highly integrated: integrates Flash, SRAM, EEPROM and multiple peripherals to reduce external component requirements.

LPC11E68JBD48 - Application Areas:

Industrial control: PLC, sensor interface, motor control.

Consumer electronics: smart home appliances, remote controls, toys.

Internet of Things (IoT): smart sensors, wireless nodes, gateway devices.

Smart home: lighting control, security system, environment monitoring.

Medical devices: portable medical instruments, health monitoring devices.

For more information, please call Mingjiada Electronics.

QQ：1668527835

Tel：13410018555

Email: chen13410018555@163.com

Company home page URL: www.hkmjd.com

The NXP LPC11E68JBD48 is a powerful and easy-to-use entry-level 32-bit microcontroller suitable for a wide range of application scenarios. Both beginners and experienced developers can quickly get started and achieve efficient development.
