(Distributed TI) Operational Amplifiers TLV9044IDYYR TLV9044 for Power Sensitive Applications

(Distributed TI) Operational Amplifiers TLV9044IDYYR TLV9044 for Power Sensitive Applications

Source:our siteTime:2023-10-30Views:

Shenzhen Mingjiada Electronics Co., Ltd. new and original (distribution TI) TLV9044IDYYR TLV9044 four-channel, 5.5V, 350kHz, ultra-low 1.2V, low quiescent current (10μA) operational amplifierProduct DescriptionThe low-power TLV9044IDYYR is a four-cha…

Shenzhen Mingjiada Electronics Co., Ltd. new and original (distribution TI) TLV9044IDYYR TLV9044 four-channel, 5.5V, 350kHz, ultra-low 1.2V, low quiescent current (10μA) operational amplifier


Product Description

The low-power TLV9044IDYYR is a four-channel, ultra-low voltage (1.2V to 5.5V) operational amplifier with rail-to-rail input and output swing. the TLV904x achieves power savings with its low quiescent current (10 µA, typical) and ability to operate from supply voltages as low as 1.2V, making the TLV904x one of the few amplifiers in the industry that can support 1.5V coin-cell applications. amplifier to support 1.5V coin cell applications.


Product Attributes

Product Category: Operational Amplifiers - Op Amps

Mounting Style: SMD/SMT

Package / Case: SOT-23-14

Number of Channels: 4 Channel

Supply Voltage - Max: 5.5 V

Vos - Input Bias Voltage : 600 uV

Supply Voltage - Min: 1.2 V

Minimum operating temperature: - 40 C

Maximum operating temperature: + 125 C

Ib - Input bias current: 1 pA

Shutdown

CMRR - Common Mode Rejection Ratio: 60 dB

en - Input voltage noise density: 85 nV sqrt Hz

Series: TLV9044

In - Input noise current density: 20 fA sqrt Hz

Ios - Input bias current : 500 fA

Product: RRIO Operational Amplifiers

Product Type: Op Amps - Operational Amplifiers

Factory Package Quantity: 3000

Sub Category: Amplifier ICs


Product Applications

- Portable Electronics

- Wearable Fitness and Activity Monitors

- Headsets/Earphones and Earbuds

- Personal Electronics

- Building automation

- Wearables (non-medical)

- Motion detectors (PIR, uWave, etc.)

- Electronic Point of Sale (EPOS)

- Single-supply, low-side, unidirectional current detection circuits
