(Silicon) BGM220SC22HNA2 Wireless Gecko Bluetooth ® module 2.4GHz to 2.4835GHz integrated, chip

(Silicon) BGM220SC22HNA2 Wireless Gecko Bluetooth ® module 2.4GHz to 2.4835GHz integrated, chip

Source:本站Time:2023-10-12Views:

Recycled and supplied (Silicon) BGM220SC22HNA2 Wireless Gecko Bluetooth module 2.4GHz to 2.4835GHz integrated, chip.Overview:The Silicon Labs BGM220S Wireless Gecko Bluetooth module is designed to meet the performance, safety and reliability require…

Recycled and supplied (Silicon) BGM220SC22HNA2 Wireless Gecko Bluetooth ® module 2.4GHz to 2.4835GHz integrated, chip.


Overview:

The Silicon Labs BGM220S Wireless Gecko Bluetooth ® module is designed to meet the performance, safety and reliability requirements of battery-powered iot products operating on Bluetooth networks. These devices are based on EFR32BG22 system-on-chip (SoC) and enable Bluetooth Low Power (BLE) connectivity. These Bluetooth modules offer the best RF range and performance, as well as future-proof capabilities that enable feature and OTA firmware updates, enhanced security features, and low power consumption. The BGM220S module is a complete solution with a fully upgradeable, robust software stack, global regulatory certification, advanced development and debugging tools.


The BGM220S Wireless Gecko Bluetooth module provides support that minimizes and simplifies engineering and development efforts for end products and helps accelerate product time-to-market.


Features:

Bluetooth 5.2

Based on EFR32BG22 SoC

Built-in antenna or RF pins

Optimal selection of MCU peripherals


BGM220SC22HNA2 Specification:

Tx Power: up to 6dBm

RX sensitivity: -98.6dBm BLE (1Mbps)

Up to 25 GPIO pins

32-bit Arm Cortex-M33 core, up to 76.8MHz

512kB flash memory, 32kB RAM memory

Wide supply voltage range: 1.8V to 3.8V

Versions from -40°C to +105°C and -40°C to +85°C

6.0mm x 6.0mm


The BGM220S is suitable for a wide range of applications, including:

• Asset tags and beacons

• Portable medical

• Sports, fitness and health equipment

• Connected home

• Industrial and building automation


If interested, please contact Mr. Chen:

Email: sales@hkmjd.com

Company website: www.hkmjd.com
