Shenzhen Mingjiada Electronics Co., Ltd. supplies new and original ST high-performance microcontroller STM32H743IIK6 ARM® Cortex®-M7 STM32H7 microcontroller IC 32-bit single-core 480MHz 2MB (2M x 8) flash memory

Manufacturer: STMicroelectronics

Part Number: STM32H743IIK6

Lot: Latest 23+

Description: IC MCU 32BIT 2MB FLASH 176UFBGA

Functional Features

Includes ST's most advanced patented technology

Kernel

- 32-bit Arm® Cortex®-M7 core with double-precision FPU and L1 cache: 16 Kbytes data cache and 16 Kbytes instruction cache and 16 Kbytes instruction cache; up to 480 MHz, MP up to 480 MHz, MPU, 1027 DMIPS/2.14 DMIPS/MHz (Dhrystone 2.1), and DSP instructions

Memory

- Up to 2 Mbytes of Flash with read/write support

- Up to 1 Mbyte of RAM: 192 Kbytes of TCMRAM (including 64 Kbytes of ITCM RAM + 128 Kbytes of DTCM RAM) 128 Kbytes of DTCM RAM for time-critical use Up to 864 Kbytes of user SRAM, with 4 kilobytes of backing fields SRAM

- Dual-mode Quad-SPI memory interface Runs up to 133 MHz

- Flexible external memory controllers up to 32-bit data bus: SRAM, PSRAM, SDRAM/LPSDR SDRAM, NOR/NAND Flash in synchronous mode

- CRC calculation unit

Security

- ROP, PC-ROP, active tampering

General purpose inputs/outputs

- Up to 168 I/O ports with interrupt capability

Reset and power management

- 3 independent power domains that can be independently clock gated or turned off:

- D1: High-performance functions

- D2: Communication peripherals and timers

- D3: Reset/clock control/power management

- 1.62 to 3.6 V Application Power and I/O

- POR, PDR, PVD, and BOR

- Dedicated USB power supply with embedded 3.3 V internal regulator to power internal PHYs

- Embedded regulators (LDOs) with configurable, scalable outputs to power digital circuits

- Voltage scaling in run and stop modes (6 configurable ranges)

- Backup regulator (~0.9 V)

- Voltage reference for analog peripherals / VREF+

- Low power modes: sleep, stop, standby and VBAT Battery charging support

High-priced acquisition of ST microcontroller STM32H743IIK6 32-bit microcontroller - MCU, only formal channel sources, such as agents, traders, terminal factory, etc., do not accept is not a formal channel sources.

Honest recycling of electronic dull inventory: electronic components, 5G module, new energy module, 5G chip, base station IC, artificial intelligence IC, network IC, Bluetooth IC, cell phone IC, automotive IC, communication IC, home appliance IC, power supply IC, driver IC, Internet of Things IC and module chips, connectors, RF modules, memory, relays, MOS tubes, MCUs, two or three-level tube and other products.
