Shenzhen Mingjiada Electronics Co., Ltd. supplies NXP microcontroller SPC5644AF0MMG2 Ultra-reliable MPC564xA MCU for automotive and industrial engine management

Supply：SPC5644AF0MMG2

Batch: Latest

Description: e200z4 MPC56xx Qorivva Microcontroller IC 32-bit Single Core 120MHz 4MB (4M x 8) Flash 208-BGA (17x17)

OVERVIEW

The MPC564xA family of MCUs features enhanced powertrain functionality and is designed to withstand the harsh environments found in mid-range gasoline and direct injection engines, advanced transmissions and industrial control applications.

Designed to help reduce overall system costs

Delivers higher performance than single-shot cores at the same frequency

Low power operation for high temperature environments such as drivelines

Enables precise tuning to optimize fuel economy and reduce emissions

Improved shift control

Features

Up to 150 MHz Power Architecture® core with two instructions per cycle

Up to 4 MB of on-chip Flash memory with ECC and RWW options

Up to 192 KB of on-chip RAM with standby (32 KB) and ECC

8 KB instruction cache (with line lock), configurable in two or four ways

3 eSCI, 3 DSPI with microsecond bus support with a reaction module

3 FlexCAN with 64 message buffers, 1 FlexRayTM module (v2.1)

32 channels eTPU2 (second generation eTPU) and 24 unified eMIOS channels

Up to 40-channel ADC (dual ADC) with 670 ns conversion time

Single 5V supply with external regulator for multiple external supplies: 5V, 3.3V and 1.2V

Power saving modes: slow, stop and standby modes

Product Attributes

Core Processor: e200z4

Core specification: 32-bit single core

Speed: 120MHz

Connectivity: CANbus, EBI/EMI, LINbus, SCI, SPI

Peripherals: DMA, POR, PWM, WDT

Number of I/O: 120

Program memory capacity: 4MB (4M x 8)

Program Memory Type: Flash

RAM Size: 192K x 8

Voltage - Supply (Vcc/Vdd): 1.14V ~ 5.25V

Data Converter: A/D 40x12b

Oscillator Type: Internal

Operating Temperature: -40°C ~ 125°C (TA)

Mounting Type: Surface Mount

Package/Housing: 208-BGA

Supplier Device Package: 208-BGA (17x17)
