Overview of the S29GL256S10DHB023

The S29GL256S10DHB023 is a 256Mb NOR Flash memory from Infineon Technologies, based on 65nm MirrorBit Eclipse technology and designed for industrial control, automotive electronics and high reliability embedded systems. Its core strengths include high speed access, low power consumption and excellent endurance for data storage needs in harsh environments916.

Core Parameters and Technical Characteristics

1. Basic Specifications

Storage capacity: 256Mb (32MB), supports 16-bit parallel interface, meets the needs of large data volume and fast reading and writing.

Operating voltage: 2.7V~3.6V, compatible with low power consumption design.

Speed Performance

Random read time: 100ns (max).

Programming Speed: Supports page programming mode, can write 256 words/512 bytes in a single pass, which significantly improves the efficiency of batch writing.

Durability: Supports 100,000 erase/write cycles and data retention up to 20 years.

2. Packaging and Reliability

Package: 64-FBGA (9×9mm), compact design for high density PCB layout.

Temperature range: -40°C to +105°C, industrial grade and automotive grade (AEC-Q100 Grade 2) compliant, adaptable to extreme environments.

3. Advanced Features

Error Checking and Correction (ECC): Built-in hardware ECC unit to ensure data integrity.

Flexible protection mechanisms.

OTP (One Time Programming) Area: Provides 1024 bytes of locked space to store critical code or encrypted information.

Sector Protection: Supports both hardware and software protection to prevent misuse.

Typical Application Scenarios

1. Industrial Automation

PLC Controller: Stores firmware and real-time configuration parameters to support fast startup and fault recovery.

Sensor network: Stable recording of sensor data in high temperature and high humidity environments.

2. Automotive electronics

ECU (Electronic Control Unit): Stores engine management and ADAS system code to meet vehicle-grade reliability requirements.

In-vehicle infotainment system: Fast loading of operating system and multimedia data to enhance user experience.

3. Medical and Aerospace

Medical imaging equipment: Ensure high-precision storage and fast retrieval of diagnostic data.

Aerospace electronic systems: Maintain long-term data stability under radiation and extreme temperatures.

Product Benefits Summary

High Reliability Design: Industrial temperature range and ECC technology to ensure stable operation in harsh environments.

High Performance Interface: Parallel interface and page programming mode optimise data throughput efficiency.

Long Life Cycle Support: 20-year data retention and 100,000 erasures reduce system maintenance costs.

Flexible security: OTP region and sector protection mechanism to meet diversified security requirements.
