Shenzhen Mingjiada Electronics New and Original Infineon MEMS Sensor_AIS328DQTR_High Performance Ultra Low Power 3-Axis Accelerometer with Digital Output for Automotive Applications.

Description of AIS328DQTR

The AIS328DQTR is an ultra-low power high performance 3-axis linear accelerometer with digital serial interface SPI standard output. An I²C compatible interface is also available. The device features an ultra-low power operating mode for advanced power saving and intelligent sleep-wake functionality.The AIS328DQTR has a dynamic user-selectable full scale range of ±2g/±4g/±8g and is capable of measuring acceleration at output data rates from 0.5 Hz to 1 kHz. A self-test feature allows the user to check the sensor's functionality in the final application. The device can be configured to generate interrupt signals from inertial wake-up events or from the position of the device itself. The timing of the thresholds and interrupt generators can be programmed on-the-fly by the end user.The AIS328DQTR is available in a small quad-flat no-lead package (QFPN) with a 4x4 mm footprint, which allows it to comply with the trend towards application miniaturisation and guarantees operation over the temperature range -40 °C to +105 °C. The AIS328DQTR is also available in a low-profile, low-profile package (QFPN) with a 4x4 mm footprint.

Features

 AEC-Q100 certified

 Wide supply voltage range: 2.4 V to 3.6 V

 Low voltage compatible IO: 1.8 V

 Ultra-low power mode power consumption: down to 10 μA

 ±2g/±4g/±8g dynamically selectable full scale

 SPI / I²C digital output interface

 16-bit data output

 2 independent programmable interrupt generators

 System sleep/wake function

 Extended temperature range: -40 °C to 105 °C

 Embedded self-test

 High shock resistance: up to 10000 g

 ECOPACK, RoHS and ‘green’ compliant

Applications

 Telematics and black boxes

 In-car navigation

 Tilt/inclination measurement

 Anti-theft devices

 Smart power saving

 Impact recognition and recording

 Vibration monitoring and compensation

 Motion activation function
