Mingjiada Electronics (Supply, Recycle) Automotive MCU S4MF03107SPZQQ1 16/32-bit RISC Flash Microcontroller, Recycling of Electronic Dull ICs for Personal Stock, Factory Stock, Customs Seizure, Consignment, Resale, Clearance and so on.

Description

The S4MF03107SPZQQ1 device is part of Texas Instruments' (TI) TMS470M family of automotive-grade 16/32-bit Reduced Instruction Set Computer (RISC) microcontrollers. The TMS470M microcontrollers deliver high performance with a highly efficient Cortex™-M3 16-/32-bit RISC central processing unit (CPU), which enables high instruction throughput and maintains improved code efficiency. The TMS470M devices utilise a big-endian byte-order format where the most significant byte of a word is stored in the least significant byte and the least significant byte is stored in the most significant byte.

High-end embedded control applications require their controllers to deliver more performance and keep costs low. The TMS470M microcontroller architecture provides a solution to these performance and cost requirements while maintaining low power consumption.

The S4MF03107SPZQQ1 device consists of the following:

- 16/32-bit RISC CPU core

- TMS470MF04207 Up to 448K bytes of program flash (with SECDED ECC)

- TTMS470MF03107 Program Flash up to 320K bytes (with SECDED ECC)

- 64K bytes of Flash memory with SECDED ECC (for additional programme space or EEPROM emulation)

- Up to 24K bytes of static RAM (SRAM) with SECDED ECC

- Real-time interrupt timer (RTI)

- Vector Interrupt Module (VIM)

- Hardware built-in self-test (BIST) verifier for SRAM (MBIST) and CPU (LBIST)

- 64-bit cyclic redundancy checker (CRC)

- FMzPLL-based clock module (with prescaler)

- Two Multi-buffered Serial Peripheral Interfaces (MibSPI)

- Two UARTs with Local Interconnect Network Interface (LIN) (SCI)

- Two CAN controllers (DCAN)

- High-End Timer (HET)

- External Clock Prescaler (ECP) Module

- One 16-channel 10-bit multi-buffered ADC (MibADC)

- Error Signalling Module (ESM)

- 4 dedicated general purpose I/O (GIO) pins and 45 additional peripheral I/O (100-pin package)
