Shenzhen Mingjiaoda Electronics Co., Ltd. imports and supplies Infineon motor control IC TLE92108-232QX multiplexed MOSFET drivers are ideally suited for applications involving automotive DC motor and solenoid control, such as power seat modules, power closure systems, and more.

Device Overview

The TLE92108-232QX is a multi MOSFET driver IC designed to control up to sixteen n-channel MOSFETs. it includes eight half-bridges for use in DC motor control applications such as automotive power seat control or other applications.

A 24-bit serial peripheral interface (SPI) is used to configure the TLE92108-232QX and control the half-bridges. It also allows the status register to be read for diagnostics.

The TLE92108-232QX provides a variety of diagnostic functions such as monitoring supply voltage, charge pump voltage, temperature warning, and overtemperature shutdown. Each gate driver can independently monitor its external MOSFET drain-source voltage for fault conditions.

The TLE92108-232QX multi MOSFET driver is available in a VQFN-48 package with exposed pads to support optical lead termination detection while providing optimal thermal performance and minimising required PCB space.

Features

-Eight half-bridge gate drivers for external N-channel MOSFETs

-Control of reverse battery-protected MOSFETs

-Adaptive MOSFET gate control

-Improved electromagnetic emissions

-Reduced switching losses in PWM mode

-24-bit serial peripheral interface

-Two current sense amplifiers with configurable gain

-High- and low-end capable of protection and diagnostics

-Emission source monitoring for short circuit detection

-Overtemperature warning and shutdown

-Timeout watchdog

-Detailed disconnected state diagnostics via SPI (open load, short to battery or short to GND)

-Three PWM inputs

-With high-side and low-side PWM functions

-Active freewheeling

-Up to 25 kHz PWM frequency

-Low current consumption in sleep mode

-Configurable low-side 1-4 actuator with short-circuit detection in sleep mode and normal mode

-Configurable VS overvoltage detection in sleep mode

-Leadless power packs with support for optical lead tip inspection

-Green product (RoHS compliant)

-AEC qualified

Potential Applications

-Seat control and extended functions (steering column adjustment, accelerator adjustment)

-Power liftgate

-Centre door locking

-Body control modules (luggage compartment lid, washer fluid pump, window lift, rear wiper...)
