Shenzhen Mingjiada Electronics Co., Ltd. is a new and original supplier of microcontrollers STM32G031G8U6 based on the high-performance Arm® Cortex®-M0+ 32-bit RISC core, operating at up to 64MHz.

Product Model：STM32G031G8U6

Year: Latest 23+

Package: 28-UFQFPN

The STM32G031G8U6 devices integrate a memory protection unit (MPU), high-speed embedded memory (8KB of SRAM and up to 64KB of Flash program memory with read protection, write protection, proprietary code protection and secure areas), DMA, extensive system functions, enhanced I/O and peripherals. These devices offer standard communication interfaces (two I2C, two SPI/one I2S and two USART), a 12-bit ADC (2.5 MSps) with up to 19 channels, an internal voltage reference buffer, a low-power RTC, an advanced control PWM timer running at up to twice the CPU frequency, four general-purpose 16-bit timers, a 32-bit general-purpose timer, two low-power 16-bit timers, two watchdog timers, and a SysTick timer.

The STM32G031G8U6 devices operate from -40 to 125°C and have a supply voltage of 1.7 V to 3.6 V. Optimised dynamic consumption combined with a comprehensive set of power saving modes, low power timers and low power UARTs allow the design of low power applications.

Product Type: ARM Microcontrollers - MCUs

Family: STM32G0

Mounting Style: SMD/SMT

Package / Case: UFQFPN-28

Core: ARM Cortex M0+

Program memory size: 64 kB

Data bus width: 32 bit

ADC resolution: 12 bit

Max. clock frequency: 64 MHz

Number of inputs/outputs: 26 I/O

Data RAM size: 8 kB

Supply voltage - min: 1.7 V

Supply voltage - max: 3.6 V

Min. operating temperature: - 40 C

Max. operating temperature: + 85 C

The STM32G031G8U6 32-bit microcontrollers (MCUs) are suitable for applications in the consumer, industrial and home appliance sectors and are ready for use in Internet of Things (IoT) solutions.
