Shenzhen Mingjiada Electronics Co., Ltd. original stock supply 12-bit ADC AD7276ARMZ AD7276 analog-to-digital converter - ADC 00Bit 3MSPS SAR ADC I. C. Quality assurance, price advantage, welcome to consult, real single has accepted price can be discussed in detail, Tel: +86 13410018555, E-mail: sales@hkmjd.com Product Description

Product description:

The AD7276ARMZ uses advanced design techniques to achieve extremely low power dissipation at high throughput rates. The device's reference is taken internally from VDD. this gives the ADC the widest dynamic input range; therefore, the device has an analog input range of 0 to VDD. the conversion rate is determined by SCLK.

Product properties:

Product Type: Analog to Digital Converters - ADCs

Family: AD7276

Mounting Style: SMD/SMT

Package / Case: MSOP-8

Resolution: 12 bit

Number of Channels: 1 Channel

Interface type: Microwire, QSPI, SPI

Sampling ratio: 3 MS/s

Input type: Single-Ended

Structure: SAR

SNR - Signal to Noise Ratio: 70 dB

Minimum operating temperature: - 40 C

Maximum operating temperature: + 125 C

Development Kit: EVAL-AD7276SDZ

DNL - Differential nonlinearity: - 0.99 LSB/1.2 LSB

FPBW - Full Power Bandwidth: 55 MHz

Gain error: +/- 3.5 LSB

Height: 0.85 mm

INL - Integral non-linearity: +/- 1.5 LSB

Input voltage: 3 V

Length: 3 mm

Number of ADC inputs: 1 Input

Number of converters: 1 Converter

Operating supply voltage: 3.3 V

Pd-Power dissipation: 19.8 mW

Power consumption: 12.6 mW

Product: ADC

Reference type: External

Reference voltage: 2.35 V

Sample and Hold: Yes

SFDR - Spurious-free dynamic range: - 80 dB

Shutdown: No Shutdown

SINAD - Signal to Noise and Distortion Ratio: 68 dB

Factory Packed Quantity: 50

Sub Category: Data Converter ICs

Supply Voltage - Max: 3.3 V

Supply voltage - min: 3.3 V

THD - Total Harmonic Distortion: - 73 dB

Type: S/H ADC

Width: 3 mm

Unit weight: 140 mg
