The LPC4337JET256 microcontroller features an asymmetric dual-core digital signal controller architecture with ARM® Cortex™-M4 and Cortex-M0 processors. These NXP Cortex-M4 MCUS are equipped with Cortex-M0 coprocessors, which have the advantage of enabling digital signal processor (DSP) and MCU applications to be developed in a single architecture, development environment. The LPC4300 series Cortex-M4 processor combines the benefits of the MCU with digital signal processing capabilities such as single-cycle MAC, single-instruction Multi-data (SIMD) technology, saturation algorithms, and floating-point units. The Cortex-M0 coprocessor offloads many of the data movement and I/O processing tasks that consume the bandwidth of the Cortex-M4 core. With its dual-core architecture and unique set of configurable peripherals, NXP Semiconductors LPC4300 MCU can be used to develop a wide range of applications such as motor control, power management, industrial automation, robotics, medical devices, automotive accessories, and embedded audio.

specification

Core processor: ARM® Cortex®-M4/M0

Kernel specification: 32-bit dual-core

Speed: 204MHz

Connection capability: CANbus, EBI/EMI, Ethernet, I²C, IrDA, Microwire, QEI, SD, PI, SI, SP, ART/USART, USB, SB OTG

Peripheral: undervoltage detection/reset, DMA, I²S, motor control PWM, POR, PWM, WDT

I/O count: 164

Program storage capacity: 1MB (1M x 8)

Program memory type: Flash

EEPROM Capacity: 16K x 8

RAM size: 136K x 8

Voltage-supply (Vcc/Vdd) : 2.2V ~ 3.6V

Data converter: A/D 8x10b; D/A 1x10b

Oscillator type: Internal

Operating temperature: -40°C ~ 105°C (TA)

Mounting type: surface mount type

Package/case: 256-LBGA (17x17)
