5-1634506-1 is a high-performance straight PCB-mounted BNC socket connector belonging to the RF/coaxial connector series. This connector is designed for high-frequency signal transmission and offers excellent electrical performance and mechanical stability.

5-1634506-1 Product Features

50Ω Impedance: Ensures stable and complete signal transmission

Nickel Plating: Provides excellent corrosion resistance and conductivity

Operating Frequency Range: 0Hz to 4GHz, suitable for a wide range of RF applications

Mounting Type: Through-hole mounting, suitable for direct soldering to PCB boards

Contact material: Phosphor bronze, with gold-plated centre contact, ensuring low contact resistance and high reliability

Dielectric material: Poly(methyl pentene) (PMP), offering excellent high-frequency performance

Operating temperature range: -55°C to +85°C, suitable for various environmental conditions

Voltage rating: 500V

Insulation resistance: 5000MΩ

5-1634506-1 Product Attributes

Product Type: RF Connector/Coaxial Connector

Product: PCB Receptacles

RF Series: BNC

Type: Jack (Socket)

Impedance: 50 Ohms

Maximum Frequency: 4 GHz

Termination Type: Solder

Direction: Straight

Polarity: Standard

Mounting Style:    Through Hole

Package:    Bulk

Body Surface Finish:    Nickel

Body Material:    Zinc

Body Type:    Straight

Brand:    TE Connectivity

Contact Material:    Phosphor Bronze

Contact Plating:    Gold

Maximum Operating Temperature:    +85°C

Minimum Operating Temperature:    -55°C

5-1634506-1 Application Range

RF Communications: Suitable for RF signal transmission and processing equipment.

Medical Devices: Such as ultrasound equipment, RF therapy devices, etc.

Sensors and Instruments: Used in high-precision measurement and testing equipment.

Industrial Automation: Used in industrial control systems requiring high-frequency signal transmission.
