5-1415020-1 is a general-purpose power relay from the Schrack series under TE Connectivity, featuring an SPST-NO (1 Form A) contact configuration, suitable for switch control applications driven by a 12VDC coil. This relay features through-hole mounting, is packaged in bulk, and has a contact rating of 12A and a switching voltage of 250VAC, making it suitable for a wide range of applications including industrial control, home appliances, and power management.

5-1415020-1 Core Features

Contact rated current: 12A (maximum 25A), suitable for medium to low-power switch control applications.

Switching voltage: 250VAC, supporting AC load switching.

Silver-nickel (AgNi) contacts provide low contact resistance and long service life.

Dimensions: 29mm × 12.7mm × 15.7mm, suitable for space-constrained designs.

Through-hole pins (Solder Pin), convenient for PCB soldering installation.

Non-latching coil, suitable for standard switch control.

Wide operating temperature range, adaptable to different environmental requirements.

5-1415020-1 Product Attributes

Product Type: General-purpose relay

Product: Power Relays

Coil Voltage: 12 VDC

Relay Contact Form: 1 Form A (SPST-NO)

Contact Current Rating: 12 A

Contact Termination: Solder Pin

Mounting Style: Through Hole

Switching Voltage: 250 VAC

Coil Type:    Non-Latching

Contact Material:    Silver Nickel (AgNi)

Length:    29 mm

Width:    12.7 mm

Height:    15.7 mm

Package:    Bulk

Contact Form:    SPST (1 Form A)

Maximum Switching Current:    25 A
