744773047 is a surface-mount (SMD) power inductor from the WE-PD2 series launched by Würth Elektronik, featuring a 4532 package (4.5mm × 4mm × 3.2mm), with an inductance value of 4.7μH, a rated current of 1.82A, and a maximum DC resistance of 110mΩ. It is suitable for applications such as switching power supplies (DC-DC), power management, and industrial control.

This inductor uses a ferrite core and wound structure, offering high current carrying capacity and low loss, making it suitable for high-efficiency switching power supplies in applications such as computers, portable devices, mobile phones, and DC-DC converters.

744773047 Features

High current carrying capacity

Rated current 1.82A, saturation current (Isat) 2.46A, suitable for high-current applications.

Low DC resistance (DCR) 110mΩ, reducing power loss.

Wide temperature operating range: -40°C to +125°C, suitable for industrial and automotive electronic environments.

Unshielded design: open structure, suitable for high-density PCB layouts, reducing electromagnetic interference (EMI) effects.

High self-resonant frequency (SRF): 45MHz, suitable for high-frequency switching power supplies, reducing the impact of parasitic capacitance.

Technical Specifications

Brand: Würth Elektronik

Model: 744773047

Package: 4532 (4.5mm × 4mm × 3.2mm)

Inductance value: 4.7 μH

Tolerance: ±20%

Rated current (Irms): 1.82 A

Saturation current (Isat): 2.46 A

DC resistance (DCR): ≤110 mΩ

Self-resonant frequency (SRF): 45 MHz

Test Frequency: 10kHz

Operating Temperature: -40°C to +125°C

Shielding Type: Unshielded

Core Material: Ferrite

Mounting Method: Surface Mount (SMD)
