DSPIC33EP256MC204-E/PT is designed to execute digital filter algorithms and high-speed precision digital control loops, ideal for applications that need to perform under pressure.

Features Of DSPIC33EP256MC204-E/PT

Operating Conditions

Up to 16 MIPS operation (3.0-3.6V)

3.0V to 3.6V, -40°C to +125°C, DC to 16 MIPS

3.0V to 3.6V, -40°C to +150°C, DC to 5 MIPS

High-performance dsPIC33F core

Code-Efficient (C and Assembly) Architecture

Two 40-Bit Wide Accumulators

Single-Cycle (MAC/MPY) with Dual Data Fetch

Single-Cycle Mixed-Sign MUL plus Hardware Divide

32-Bit Multiply Support

Clock Management

±0.25% Internal Oscillator

Programmable PLLs and Oscillator Clock Sources

Fail-Safe Clock Monitor (FSCM)

Independent Watchdog Timer (WDT)

Fast Wake-up and Start-up

Power Management

Low-Power Management modes (Sleep, Idle, Doze)

Integrated Power-on Reset and Brown-out Reset

1 mA/MHz Dynamic Current (typical)

30 µA IPD Current (typical)

PWM

Up to Three PWM Pairs

Two Dead-Time Generators

31.25 ns PWM Resolution

PWM Support for: - Inverters, PFC, UPS - BLDC, PMSM, ACIM, SRM

Class B-Compliant Fault Inputs

Possibility of ADC Synchronization with PWM Signal

Advanced Analog Features

ADC module: - 10-bit, 1.1 Msps with four S&H

Four analog inputs on 18-pin devices and up to 14 analog inputs on 44-pin devices

Flexible and Independent ADC Trigger Sources

Three Comparator modules

Charge Time Measurement Unit (CTMU): - Supports mTouch™ capacitive touch sensing and provides high-resolution time measurement (1 ns)

On-chip temperature measurement

Timers/Output Compare/Input Capture

Up to Five General Purpose Timers: - One 16-bit and up to two 32-bit timers/counters

Two Output Compare modules

Three Input Capture modules

Peripheral Pin Select (PPS) to allow Function Remap

Communication Interfaces

UART module (4 Mbps): - With support for LIN/J2602 Protocols and IrDA®

4-Wire SPI module (8 MHz maximum speed): - Remappable pins in 32-Kbyte Flash devices

I2C™ module (400 kHz)

Input/Output

Sink/Source 10 mA or 6 mA, Pin-Specific for Standard VOH/VOL, up to 16 mA or 12 mA for Non-Standard VOH1

5V Tolerant Pins

Up to 20 Selectable Open-Drain and Pull-ups

Three External Interrupts (two are remappable)

Debugger Development Support

In-Circuit and In-Application Programming

Up to Three Complex Data Breakpoints

Trace and Run-Time Watch
